50 Ton Truck Weighing Load Cell Sensor 2.0mv/v Output

Produktdetails:

Herkunftsort:	China
Markenname:	RJ
Zertifizierung:	CE/ROSE
Modellnummer:	RJ

Ausführliche Information

Herkunftsort:

China

Markenname:

Zertifizierung:

CE/ROSE

Modellnummer:

Ausgabe:

2.0vm/v

Kapazität:

3~120kg

Nennleistung:

2.0±0.2

Nichtlinearität:

0,03 % vom Endwert

Hysterese:

0,03 % vom Endwert

Wiederholbarkeit:

0,03 % vom Endwert

Hervorheben:

High Light

Hervorheben:

50 ton load cell sensor

truck weighing load cell

2.0mv/v output load cell

Handelsinformationen

Min Bestellmenge:

Preis:

$5-10

Verpackung Informationen:

Karton oder hölzerne Kiste

Lieferzeit:

5-8 Arbeitstage

Zahlungsbedingungen:

Akkreditiv, Dokumenteninkasso, Dokument gegen Zahlung, Überweisung, Western Union

Versorgungsmaterial-Fähigkeit:

2000PC/Month

Produkt-Beschreibung

Truck 50 Ton Weighing Scale Load Cell

50 Ton Truck Weighing Load Cell Sensor 2.0mv/v Output 0

Load cells are used in smart devices, smart vending cabinets, smart garbage bins, weight detection equipment, etc., and are easy to install and operate.

Specifications
Rated Output	mv/v	2.0±0.2
Non-linearity	%F.S	0.03%F.S
Hysteresis	%F.S	0.03
Repeatability	%F.S	0.03
Creep	%F.S/3min	0.03
Temp.effect on zero	%F.S/10℃	0.03%F.S
Temp.effect on span	%F.S/10℃	0.05%F.S
Zero balance	mv/v	±0.05
Input impedance	Ω	405±6
Output impedance	Ω	350±5
Insulation resistance	MΩ	≥2000(100VDC)
Recommended excitation voltage	VDC	3~12
Allowed excitation voltage	VDC	3~12
Compensated temp.Range	℃	-10℃~+40℃
Operating temp.Range	℃	0℃~+40℃
Safe overload	%F.S	120
Ultimate Overload	%F.S	150
Connection	Excitation: Red:+ Black:-
Connection	Signal: Green:+ White:-

50 Ton Truck Weighing Load Cell Sensor 2.0mv/v Output 1

Packing & Transport

50 Ton Truck Weighing Load Cell Sensor 2.0mv/v Output 2

FAQ

Q: How can I get the quotation?
Please send your inquiry to us.
Click 'Contact Supplier' icon which is on the right-side or write down your requirement at the bottom of this page.

Q: What detailed information do I need to provide if I want to place an order?

We need to know the following information:
Capacity, Usage and other related parameters you need.

Q: Do you have any discount?
Yes, we take bulk order, if you buy large QTY, please send us inquiry, we can discuss the price.

Q: Can I get samples?
Yes, if you have the follower orders, we could offer the samples or free samples for you.

Q: How about the quality of the products?
We have the certification of CE and RoHs , also we are the Alibaba's verified supplier, you don't have to worry about this.

Q: When will you arrange the production?
We will arrange the production immediately after receiving your payment.

Q: Could you provide me the shortest lead time?
We have materials in our stock, if you really need, let's discuss and we will try our best to satisfy you.
